container oxygen generator supplier

Container Oxygen Generator

These units have been in production for many years now and work by pumping compressed air into containers when they need it. They look like portable compressors but are very user-friendly because all you need to do is connect them to available USB ports.

Oxygen Capacity: 1-100Nm³/hr
Oxygen Purity: 90-95%
Oxygen Pressure: 0.1-0.5Mpa (150-200Bar Refilling Pressure can be offered)

Product Description

Container Oxygen Generators can be integrated with a compressor or oxygen cylinder filling station up to 99% purity within a container for easy shipping and on-demand, low-cost oxygen generation. To meet your specs, we can manufacture a highly efficient generation system for separating oxygen gas from the air, completely enclosed within a container.

1. System Composition of China Container Oxygen Generator

1) Air compressor: electric drive or generator drive, air-cooled screw air compressor.
2) Air purification system: with air buffer tank, air dryer, filters, etc.
3) China PSA oxygen generator manufacturer: with adsorption towers, control system, etc.
4) Oxygen booster: can rise oxygen pressure up to 200 bar.
5) Cylinder refilling system (optional): with manifold and oxygen cylinders.
PSA container oxygen generator from a China factory uses clean compressed air as raw material and zeolite molecular sieve (ZMS) as adsorbent, to produce oxygen gas with Pressure Swing Adsorption (PSA) technology at normal temperature. ZMS is a round granular adsorbent full of micropores inside and outside, which has the characteristic of selective adsorption. N2 has a higher diffusion rate while O2 has a lower, therefore N2 is adsorbed into ZMS while O2 is out of it. By controlling the on/off state of the pneumatic valves by PLC, adsorbing under pressure, and regenerating without pressure, to separate nitrogen and oxygen gas, and create a continuous flow of oxygen with required purity.

2. Introduction of China Container Oxygen Generator Supplier

456

3. Features of China Container Oxygen Generator from the manufacturer

1) Adopt a human-computer interface and intelligent control to make simple operations and supply qualified oxygen gas quickly.
2) High-efficiency filling technology of molecular sieve, makes ZMS much tighter, firmer, and longer service life.
3) Adopt internationally famous brands of PLC and pneumatic valves, to switch automatically and make operation more stable.
4) Pressure, purity, and flow rate are stable and adjustable and can meet different requirements of customers.
5) Compact structure, nice appearance, and small occupation area.

4. Applications of Container Oxygen Generator from China factory

1)Sewage treatment: oxygen-enriched aeration for activated sludge, pond oxygenation, and ozone sterilization.
2)Glass melting: combustion-supporting dissolution, cutting to increase yield and extend the service life of stoves.
3)Pulp bleaching and paper making: changing chlorinated bleaching to oxygen-enriched bleaching with low-cost, sewage treatment.
4) Non-ferrous metal metallurgy: oxygen-enriched smelting of steel, zinc, nickel, lead, etc. PSA technology is gradually taking the place of cryogenic technology.
5) Petrochemical and chemical industry: increasing the reaction speed and chemical production output by adopting oxygen-enriched oxidizing reaction.
6) Ore treatment: use oxygen in gold, etc. production process, to improve precious metal extraction efficiency.
7) Aquaculture: increasing dissolved oxygen in water by oxygen-enriched aeration to vastly improve fish yield, also can use oxygen when transporting lives fish.
8) Fermentation: replacing air with oxygen in fermentation to drastically improve efficiency.
9) Drinking water: providing oxygen to the ozone generator for sterilization.
10) Medical: oxygen bar, oxygen therapy, physical health care, etc.

5. Shipment of China Container Oxygen Generator manufacturer

123 1

Hot Tags: Container Oxygen Generator supplier, Manufacturers, Suppliers, Buy, Customized, Factory, China, Made in China, Price

A battery-powered container oxygen generator: then plug them into your host computer whenever needed! They can be battery-powered or operated by electricity from batteries (I use the latter). Make sure you buy the right size unit though — large ones will take up more space than small ones!
